◆ Chassis System:
The machine features a fully diesel-powered, articulated, wheeled chassis system. Equipped with a well-known brand engine, it enables fast and easy transition between multiple working faces, maximizing operational cost-effectiveness.
◆ Exhaust Purification & Dust Control:
Exhaust gases are filtered through a water-based purification system to improve the working environment. A water pump is also integrated for effective dust suppression during scaling operations.
◆ Drivetrain & Mobility:
Full-time four-wheel drive with wet disc brakes on all wheels ensures strong mobility and safety. The articulated chassis offers a small turning radius, making the machine highly maneuverable in confined spaces.
◆ Hydraulic Hammer:
The purpose-built scaling hammer delivers an impact frequency of 600–1100 bpm and an impact energy of 362 J. It provides powerful scaling performance to remove fractured rock while minimizing damage to the tunnel roof.
◆ Cabin:
The operator's cab meets FOPS safety standards and features an ergonomic layout with a comfortable seat. The high-positioned cab design expands the operator’s field of view, while the high-strength structure ensures operator safety.
◆ Boom System:
Options include a standard boom with a maximum reach of 6 meters or a telescopic boom extending up to 8 meters. Built from high-strength steel, the boom offers superior rigidity and resistance to impact. The compact design ensures focused force application and stable movement. Dual helical swing cylinders on the hammer allow for pitch and rotation without blind spots.
◆ Control Console:
Scaling operations are managed through electro-hydraulic proportional control and a multifunctional joystick for smooth and precise boom movements. A user-friendly interface integrates work indicators and parameter displays, providing operators with clear and intuitive operation and monitoring.
◆ Chassis System:
The machine features a fully diesel-powered, articulated, wheeled chassis system. Equipped with a well-known brand engine, it enables fast and easy transition between multiple working faces, maximizing operational cost-effectiveness.
◆ Exhaust Purification & Dust Control:
Exhaust gases are filtered through a water-based purification system to improve the working environment. A water pump is also integrated for effective dust suppression during scaling operations.
◆ Drivetrain & Mobility:
Full-time four-wheel drive with wet disc brakes on all wheels ensures strong mobility and safety. The articulated chassis offers a small turning radius, making the machine highly maneuverable in confined spaces.
◆ Hydraulic Hammer:
The purpose-built scaling hammer delivers an impact frequency of 600–1100 bpm and an impact energy of 362 J. It provides powerful scaling performance to remove fractured rock while minimizing damage to the tunnel roof.
◆ Cabin:
The operator's cab meets FOPS safety standards and features an ergonomic layout with a comfortable seat. The high-positioned cab design expands the operator’s field of view, while the high-strength structure ensures operator safety.
◆ Boom System:
Options include a standard boom with a maximum reach of 6 meters or a telescopic boom extending up to 8 meters. Built from high-strength steel, the boom offers superior rigidity and resistance to impact. The compact design ensures focused force application and stable movement. Dual helical swing cylinders on the hammer allow for pitch and rotation without blind spots.
◆ Control Console:
Scaling operations are managed through electro-hydraulic proportional control and a multifunctional joystick for smooth and precise boom movements. A user-friendly interface integrates work indicators and parameter displays, providing operators with clear and intuitive operation and monitoring.
