Atlas Copco Epiroc MT42 Parts and Components
Features
OEM design
The Atlas Copco Epiroc genuine spare parts and components ensures that you will meet the peak of your machine performance while protecting both the equipment and its operators.
Carefully selected and tested
The Atlas Copco Epiroc genuine spare parts and components are selected and tested following Epiroc engineering design standards and the latest technology available. A perfect fit, these allow you to meet peak performance and protect your equipment in the toughest operating conditions.
The range of Atlas Copco Epiroc MT42 Parts and Components is designed to meet the highest standards of quality and performance. Whether you are in need of Engine Parts, Transmission Parts, Torque Converter Parts, Axle Parts, or Buckets, we have you covered.
The Engine Parts are built to deliver reliable power and efficiency, ensuring smooth operation and maximum productivity.
The Transmission Parts are engineered for durability and precision, providing seamless shifting and optimal performance.
The Torque Converter Parts are designed to deliver the power you need, when you need it, while the Axle Parts offer superior strength and stability.
The Buckets are built to withstand the toughest conditions, with high-quality materials and expert craftsmanship. From digging to hauling, our Buckets are designed to deliver exceptional performance and longevity.
Trust in the Atlas Copco Epiroc MT42 Parts and Components to keep your equipment running smoothly and efficiently. With our commitment to quality and reliability, you can count on us to provide the parts and components you need to get the job done right.
Atlas Copco Epiroc MT42 Parts and Components
Features
OEM design
The Atlas Copco Epiroc genuine spare parts and components ensures that you will meet the peak of your machine performance while protecting both the equipment and its operators.
Carefully selected and tested
The Atlas Copco Epiroc genuine spare parts and components are selected and tested following Epiroc engineering design standards and the latest technology available. A perfect fit, these allow you to meet peak performance and protect your equipment in the toughest operating conditions.
The range of Atlas Copco Epiroc MT42 Parts and Components is designed to meet the highest standards of quality and performance. Whether you are in need of Engine Parts, Transmission Parts, Torque Converter Parts, Axle Parts, or Buckets, we have you covered.
The Engine Parts are built to deliver reliable power and efficiency, ensuring smooth operation and maximum productivity.
The Transmission Parts are engineered for durability and precision, providing seamless shifting and optimal performance.
The Torque Converter Parts are designed to deliver the power you need, when you need it, while the Axle Parts offer superior strength and stability.
The Buckets are built to withstand the toughest conditions, with high-quality materials and expert craftsmanship. From digging to hauling, our Buckets are designed to deliver exceptional performance and longevity.
Trust in the Atlas Copco Epiroc MT42 Parts and Components to keep your equipment running smoothly and efficiently. With our commitment to quality and reliability, you can count on us to provide the parts and components you need to get the job done right.
Item | Name | Epiroc Part No. | Dana Part No. |
1 | TRANSMISSION ASSEMBLY | 705608 | |
2 | SNAP RING | 400793 | 247470 |
3 | INPUT CLUTCH | ||
4 | PISTON RING | 412289 | 245501 |
5 | EXPANDER SPRING | 404759 | 245502 |
6 | BOLT | 375872 | 247229 |
7 | SUPPORT ASSEMBLY | 353927 | 237169 |
8 | NUT | 378923 | 245519 |
9 | BEARING | 334001 | 225840 |
10 | SPACER | 333409 | 217508 |
11 | GEAR | 333384 | 217399 |
12 | GASKET | 333480 | 217653 |
13 | LOCKWASHER | 307029 | 4E-06 |
14 | CAPSCREW | 305018 | 1C-616 |
15 | CAPSCREW | 305013 | 1C-624 |
16 | CONTROL VALVE | 373610 | 242510 |
17 | CAPSCREW | 310417 | 1C-640 |
18 | LOCKWASHER | 307029 | 4E-06 |
19 | O RING | 339093 | 25K-40026 |
20 | DIPSTICK HOUSING | 339588 | 230610 |
21 | DIPSTICK HOUSING | 339589 | 230613 |
22 | TUBE | 334233 | 230606 |
23 | CAPSCREW | 339990 | 22F-06 |
24 | FILTER PIPE | 336801 | 5K-824 |
25 | GEAR | 333384 | 217399 |
26 | SPACER | 400797 | 247711 |
27 | SHAFT | 400798 | 247710 |
28 | FRONT BEARING | 334002 | 225842 |
29 | GASKET | 333403 | 217490 |
30 | BEARING CAP | 333402 | 217489 |
31 | SEAL | 341361 | 209587 |
32 | LOCKWASHER | 307028 | 4E-08 |
33 | CAPSCREW | 305029 | 1C-820 |
34 | INPUT FLANGE | 370575 | 217772 |
35 | O RING | 339100 | 25K-60116 |
36 | WASHER | 333738 | 222179 |
37 | NUT | 333775 | 222960 |
38 | CAPSCREW | 305029 | 1C-820 |
39 | LOCKWASHER | 307028 | 4E-08 |
40 | BEARING CUP | 333401 | 217488 |
41 | GASKET | 333403 | 217490 |
42 | NUT | 333775 | 222960 |
43 | SPACER | 333406 | 217504 |
44 | FRONT BEARING | 3334002 | 225842 |
45 | SHAFT | 400798 | 247710 |
46 | SPACER | 400797 | 247711 |
47 | SPACER | 333409 | 217508 |
48 | BEARING | 334001 | 225840 |
49 | NUT | 378923 | 245519 |
50 | SUPPORT ASSEMBLY | 353927 | 237169 |
51 | BOLT | 375872 | 247229 |
52 | PISTON RING | 412289 | 245501 |
53 | EXPANDER SPRING | 404759 | 245502 |
54 | REVERSE CLUTCH | ||
55 | SNAP RING | 400793 | 247470 |
56 | SNAP RING | 373188 | 711161 |
57 | GEAR | 333383 | 217389 |
58 | BEARING CAP | 333465 | 217629 |
59 | SHIM | 333488 | 217689 |
60 | SHIM | 333489 | 217690 |
61 | SHIM | 333490 | 217691 |
62 | BEARING CUP | 405033 | 247578 |
63 | BEARING CONE | 402848 | 247576 |
64 | BEARING CONE | 402848 | 247576 |
65 | BEARING CUP | 405033 | 247578 |
66 | SPACER | 333464 | 217628 |
67 | SNAP RING | 333824 | 223879 |
68 | OIL BAFFLE | 333449 | 217598 |
69 | IDLER SHAFT | 351153 | 235325 |
70 | BEARING | 351151 | 235322 |
71 | GEAR | 351150 | 235320 |
72 | RING | 400883 | 247463 |
73 | COVER | 333507 | 217712 |
74 | GASKET | 352712 | 237157 |
75 | SNAP RING | 378941 | 247717 |
76 | 1ST CLUTCH | ||
77 | PISTON RING | 346190 | 233948 |
78 | RING | 346189 | 233947 |
79 | BOLT | 375872 | 247229 |
80 | SUPPORT ASSEMBLY | 333351 | 217128 |
81 | SHAFT | 411254 | 248690 |
82 | BALL | 330093 | 10J-12 |
83 | BEARING ASSEMBLY | 333957 | 225400 |
84 | SNAP RING | 333835 | 223982 |
85 | SPACER | 333405 | 217502 |
86 | CASE ASSEMBLY | 363183 | 233750 |
87 | WASHER | 333739 | 222181 |
88 | BEARING | 334003 | 225844 |
89 | NUT | 378923 | 245519 |
90 | SUPPORT ASSEMBLY | 353927 | 237169 |
91 | BOLT | 375872 | 247229 |
92 | EXPANDER SPRING | 404759 | 245501 |
93 | PISTON RING | 412289 | 245502 |
94 | 3RD CLUTCH | ||
95 | LOCKWASHER | 307028 | 4E-08 |
96 | CAPSCREW | 305029 | 1C-820 |
97 | SNAP RING | 400793 | 247470 |
98 | SNAP RING | 400793 | 247470 |
99 | 4TH CLUTCH | ||
100 | EXPANDER SPRING | 404759 | 245501 |
101 | PISTON RING | 412289 | 245502 |
102 | BOLT | 375872 | 247229 |
103 | SUPPORT ASSEMBLY | 353927 | 237169 |
104 | NUT | 378923 | 245519 |
105 | BEARING | 334003 | 225844 |
106 | WASHER | 333739 | 222181 |
107 | SPACER | 333405 | 217502 |
108 | GEAR | 341456 | 217359 |
109 | GEAR | 351152 | 235324 |
110 | ELBOW | 339992 | 26F-3 |
111 | BREATHER | 359700 | 238535 |
112 | SNAP RING | 333835 | 223982 |
113 | BEARING ASSEMBLY | 333957 | 225400 |
114 | SHAFT | 411254 | 245690 |
115 | SUPPORT ASSEMBLY | 333351 | 217128 |
116 | BOLT | 375872 | 247229 |
117 | RING | 346189 | 233947 |
118 | PISTON RING | 346190 | 233948 |
119 | COTTER PIN | 329984 | 1F-632 |
120 | 2ND CLUTCH | ||
121 | SNAP RING | 378941 | 247717 |
122 | SCREW | 340003 | 25G-612 |
123 | WASHER | 339963 | 6E-06 |
124 | WASHER | 353781 | 237328 |
125 | CAPSCREW | 333103 | 21C-612 |
126 | NUT | 354022 | 201262 |
127 | WASHER | 333739 | 222181 |
128 | O RING | 400695 | 25K-60204 |
129 | FLANGE | 333395 | 217457 |
130 | CAPSCREW | 305029 | 1C-820 |
131 | LOCKWASHER | 307028 | 4E-08 |
132 | BEARING CAP | 353782 | 217625 |
133 | O RING | 340143 | 25K-40408 |
134 | OIL SEAL | 333983 | 225763 |
135 | BEARING CUP | 404764 | 247581 |
136 | BEARING CONE | 340824 | 225850 |
137 | OUTPUT SHAFT | 333536 | 218703 |
138 | GEAR | 333377 | 217343 |
139 | PLUG | 307892 | 11F-12 |
140 | WASHER | 353781 | 237328 |
141 | CAPSCREW | 333103 | 21C-612 |
142 | SUMP ASSEMBLY | 333427 | 217562 |
143 | MAGNET | 400675 | 525293 |
144 | GASKET | 353213 | 237154 |
145 | CAPSCREW | 305056 | 1C-636 |
146 | LOCKWASHER | 307029 | 4E-06 |
147 | GASKET | 333533 | 218376 |
148 | FRAME & SCREEN ASSEMBLY | 371564 | 242881 |
149 | GEAR | 405034 | 217358 |
150 | BEARING CONE | 340824 | 225850 |
151 | BEARING CUP | 404764 | 247581 |
152 | OIL SEAL | 333983 | 225763 |
153 | O RING | 340143 | 25K-40408 |
154 | SHIM | 333485 | 217686 |
155 | SHIM | 333486 | 217687 |
156 | SHIM | 333487 | 217688 |
157 | BEARING CAP | 353782 | 217625 |
158 | FLANGE | 333395 | 217457 |
159 | LOCKWASHER | 307028 | 4E-08 |
160 | CAPSCREW | 305029 | 1C-820 |
161 | O RING | 400695 | 25K-60204 |
162 | WASHER | 333739 | 222181 |
163 | COTTER PIN | 329984 | 1F-632 |
164 | NUT | 354022 | 201262 |
165 | GASKET | 353214 | 237158 |
166 | COVER | 333457 | 217619 |
167 | WASHER | 353781 | 237328 |
168 | CAPSCREW | 333103 | 21C-612 |
169 | PLUG | 336269 | 40K-04 |
170 | CASE ASSEMBLY | 363183 | 237858 |
171 | TUBE | 333504 | 217708 |
172 | TUBE | 333506 | 217710 |
173 | TUBE | 333505 | 217709 |
174 | SLEEVE | 333733 | 222067 |
175 | SLEEVE | 333733 | 222067 |
176 | TUBE | 344092 | 217698 |
177 | TUBE CLIP | 337368 | 6H-29 |
178 | RIVET | 329996 | 1H-516 |
179 | FLATWASHER | 599231 | 25E-15 |
180 | RIVET | 329997 | 1H-534 |
181 | FLATWASHER | 599231 | 25E-15 |
182 | RIVET | 337368 | 6H-29 |
183 | FLATWASHER | 599230 | 25E-13 |
184 | RIVET | 329994 | 1H-416 |
185 | TUBECLIP | 337369 | 6H-32 |
186 | TUBE | 371567 | 242924 |
187 | TUBE | 333502 | 217706 |
188 | TUBE | 333494 | 217699 |
189 | TUBE | 363184 | 238748 |
190 | TUBE | 363185 | 239182 |
191 | TUBE | 363186 | 238747 |
192 | TUBE | 333496 | 217700 |
193 | TUBE | 333501 | 217705 |
194 | TUBE | 371568 | 242772 |
195 | SLEEVE | 355985 | 221871 |
196 | SLEEVE | 355985 | 221871 |
197 | HUB ASSEMBLY | 400035 | 245503 |
198 | SPRING | 377590 | 245505 |
199 | SPRING PIN | 333450 | 217599 |
200 | DISC | 365332 | 238174 |
201 | DISC | 334055 | 227495 |
202 | PLATE | 333368 | 217161 |
203 | SNAP RING | 333350 | 217099 |
204 | PISTON | 333370 | 217164 |
205 | RING | 341457 | 217361 |
206 | PISTON RING | 333385 | 217411 |
207 | SNAP RING | 376985 | 245980 |
208 | SNAP RING | 376986 | 245981 |
209 | WASHER | 376987 | 245982 |
210 | WASHER | 376988 | 245983 |
211 | WASHER | 376989 | 245984 |
212 | BEARING CONE | 353932 | 237183 |
213 | BEARING CUP | 353931 | 237184 |
214 | RACE | 333364 | 217155 |
215 | BALL | 330092 | 10J-08 |
216 | BALL CLUTCH DRUM ASSEMBLY | 355114 | 237179 |
217 | BEARING CUP | 353928 | 237182 |
218 | BEARING CONE | 353929 | 237181 |
219 | BAFFLE RING | 333411 | 217510 |
220 | HUB ASSEMBLY | 401292 | 248290 |
221 | SPRING | 377590 | 245505 |
222 | SPRING PIN | 333450 | 217599 |
223 | DISC | 339692 | 232285 |
224 | DISC | 339705 | 232779 |
225 | PLATE | 333355 | 217137 |
226 | SNAP RING | 333387 | 217416 |
227 | PISTON | 333356 | 217138 |
228 | EXPANDER SPRING | 405036 | 245140 |
229 | PISTON RING | 405037 | 245139 |
230 | PISTON | 376395 | 246248 |
231 | EXPANDER SPRING | 376393 | 239694 |
232 | SNAP RING | 338045 | 791018 |
233 | WASHER | 354511 | 237520 |
234 | SNAP RING | 333835 | 223982 |
235 | BEARING | 333985 | 225768 |
236 | RACE | 333354 | 217136 |
237 | BALL | 330092 | 10J-08 |
238 | CLUTCH DRUM ASSEMBLY | 333352 | 217130 |
239 | BEARING | 355115 | 236781 |
240 | SNAP RING | 333820 | 223852 |
241 | GEAR | 350429 | 233714 |
242 | SNAP RING | 333491 | 217692 |
243 | CONTROL VALVE ASSEMBLY | 373610 | 242510 |
244 | PLUG | 334052 | 227418 |
245 | O RING | 367144 | 91F-7 |
246 | 3RD SPEED VALVE | 334091 | 228096 |
247 | HOSUING | 342539 | 228094 |
248 | 3RD SPEED VALVE STOP PIN | 330450 | 106358 |
249 | WASHER | 407844 | 743314 |
250 | PLUG | 334054 | 227423 |
251 | 2ND SPEED VALVE STOP PIN | 330450 | 106358 |
252 | O RING | 334947 | 25K-30030 |
253 | 2ND SPEED VALVE STOP PIN | 334090 | 228095 |
254 | 1ST SPEED VALVE | 342531 | 227550 |
255 | PLUG | 334591 | 24K-10 |
256 | PIN | 339731 | 300058 |
257 | LOCK PIN | 337658 | 654724 |
258 | PLUG | 336268 | 40K-02 |
259 | PLUG | 334053 | 227422 |
260 | WASHER | 407614 | 731964 |
261 | SELECTOR VALVE ASSEMBLY | 420932 | 227555 |
262 | VALVE PLUG | 420933 | 227556 |
263 | O RING | 334947 | 25K-30030 |
264 | VALVE SPRING | 334062 | 227558 |
265 | HOUSING PLUG | 334061 | 227557 |
266 | ADAPTOR UNION | 339994 | 36F-1 |
267 | SNAP RING | 401137 | 664140 |
268 | PISTON GUIDE | 373436 | 241396 |
269 | O RING | 372760 | 25K-20030 |
270 | PISTON GUIDE | 373437 | 241409 |
271 | CAP STOP | 373438 | 241399 |
272 | SPACER | 373439 | 241402 |
273 | SPRING | 373440 | 241398 |
274 | SLEEVE | 373441 | 244467 |
275 | PLUG | 334053 | 227422 |
276 | WASHER | 407614 | 731964 |
277 | PLUG | 307400 | 16F-08 |
278 | SPOOL | 409113 | 241404 |
279 | PISTON GUIDE | 373437 | 241409 |
280 | O RING | 372760 | 25K-20030 |
281 | PISTON GUIDE | 373436 | 241396 |
282 | SNAP RING | 401137 | 247475 |
283 | ADAPTOR UNION | 339994 | 36F-1 |
284 | PLUG | 007212 | 24K-7 |
285 | O RING | 367144 | 91F-7 |
286 | VALVE SPOOL | 333471 | 217644 |
287 | VALVE SPRING | 333472 | 217645 |
288 | VALVE STOP | 333689 | 220983 |
289 | O RING | 340124 | 25K-30018 |
290 | O RING | 334948 | 25K-40024 |
291 | SPOOL STOP | 333732 | 222041 |
292 | VALVE SPOOL | 369206 | 239527 |
293 | LOCKWASHER | 307029 | 5E-05 |
294 | CAPSCREW | 305010 | 1C-512 |
295 | COVER | 373443 | 241401 |
296 | PLUG | 336269 | 40K-04 |
297 | INNER SPRING | 333475 | 217648 |
298 | OUTER SPRING | 333476 | 217649 |
299 | SPOOL STOP | 333732 | 222041 |
300 | O RING | 334948 | 25K-40024 |
301 | O RING | 334948 | 25K-40024 |
302 | SPRING STOP | 333732 | 222041 |
303 | SAFETY VALVE SPRING | 366916 | 240140 |
304 | SAFETY VALVE SPACER | 3334790 | 217652 |
305 | SAFETY VALVE BALL | 330097 | 10J-24 |
306 | SAFETY VALVE SEAT | 333477 | 217650 |
307 | COVER PLATE | 333466 | 217632 |
308 | PLUG | 355112 | 1300085 |
309 | PLUG | 36486 | 239245 |
Item | Name | Epiroc Part No. | Dana Part No. |
1 | TRANSMISSION ASSEMBLY | 705608 | |
2 | SNAP RING | 400793 | 247470 |
3 | INPUT CLUTCH | ||
4 | PISTON RING | 412289 | 245501 |
5 | EXPANDER SPRING | 404759 | 245502 |
6 | BOLT | 375872 | 247229 |
7 | SUPPORT ASSEMBLY | 353927 | 237169 |
8 | NUT | 378923 | 245519 |
9 | BEARING | 334001 | 225840 |
10 | SPACER | 333409 | 217508 |
11 | GEAR | 333384 | 217399 |
12 | GASKET | 333480 | 217653 |
13 | LOCKWASHER | 307029 | 4E-06 |
14 | CAPSCREW | 305018 | 1C-616 |
15 | CAPSCREW | 305013 | 1C-624 |
16 | CONTROL VALVE | 373610 | 242510 |
17 | CAPSCREW | 310417 | 1C-640 |
18 | LOCKWASHER | 307029 | 4E-06 |
19 | O RING | 339093 | 25K-40026 |
20 | DIPSTICK HOUSING | 339588 | 230610 |
21 | DIPSTICK HOUSING | 339589 | 230613 |
22 | TUBE | 334233 | 230606 |
23 | CAPSCREW | 339990 | 22F-06 |
24 | FILTER PIPE | 336801 | 5K-824 |
25 | GEAR | 333384 | 217399 |
26 | SPACER | 400797 | 247711 |
27 | SHAFT | 400798 | 247710 |
28 | FRONT BEARING | 334002 | 225842 |
29 | GASKET | 333403 | 217490 |
30 | BEARING CAP | 333402 | 217489 |
31 | SEAL | 341361 | 209587 |
32 | LOCKWASHER | 307028 | 4E-08 |
33 | CAPSCREW | 305029 | 1C-820 |
34 | INPUT FLANGE | 370575 | 217772 |
35 | O RING | 339100 | 25K-60116 |
36 | WASHER | 333738 | 222179 |
37 | NUT | 333775 | 222960 |
38 | CAPSCREW | 305029 | 1C-820 |
39 | LOCKWASHER | 307028 | 4E-08 |
40 | BEARING CUP | 333401 | 217488 |
41 | GASKET | 333403 | 217490 |
42 | NUT | 333775 | 222960 |
43 | SPACER | 333406 | 217504 |
44 | FRONT BEARING | 3334002 | 225842 |
45 | SHAFT | 400798 | 247710 |
46 | SPACER | 400797 | 247711 |
47 | SPACER | 333409 | 217508 |
48 | BEARING | 334001 | 225840 |
49 | NUT | 378923 | 245519 |
50 | SUPPORT ASSEMBLY | 353927 | 237169 |
51 | BOLT | 375872 | 247229 |
52 | PISTON RING | 412289 | 245501 |
53 | EXPANDER SPRING | 404759 | 245502 |
54 | REVERSE CLUTCH | ||
55 | SNAP RING | 400793 | 247470 |
56 | SNAP RING | 373188 | 711161 |
57 | GEAR | 333383 | 217389 |
58 | BEARING CAP | 333465 | 217629 |
59 | SHIM | 333488 | 217689 |
60 | SHIM | 333489 | 217690 |
61 | SHIM | 333490 | 217691 |
62 | BEARING CUP | 405033 | 247578 |
63 | BEARING CONE | 402848 | 247576 |
64 | BEARING CONE | 402848 | 247576 |
65 | BEARING CUP | 405033 | 247578 |
66 | SPACER | 333464 | 217628 |
67 | SNAP RING | 333824 | 223879 |
68 | OIL BAFFLE | 333449 | 217598 |
69 | IDLER SHAFT | 351153 | 235325 |
70 | BEARING | 351151 | 235322 |
71 | GEAR | 351150 | 235320 |
72 | RING | 400883 | 247463 |
73 | COVER | 333507 | 217712 |
74 | GASKET | 352712 | 237157 |
75 | SNAP RING | 378941 | 247717 |
76 | 1ST CLUTCH | ||
77 | PISTON RING | 346190 | 233948 |
78 | RING | 346189 | 233947 |
79 | BOLT | 375872 | 247229 |
80 | SUPPORT ASSEMBLY | 333351 | 217128 |
81 | SHAFT | 411254 | 248690 |
82 | BALL | 330093 | 10J-12 |
83 | BEARING ASSEMBLY | 333957 | 225400 |
84 | SNAP RING | 333835 | 223982 |
85 | SPACER | 333405 | 217502 |
86 | CASE ASSEMBLY | 363183 | 233750 |
87 | WASHER | 333739 | 222181 |
88 | BEARING | 334003 | 225844 |
89 | NUT | 378923 | 245519 |
90 | SUPPORT ASSEMBLY | 353927 | 237169 |
91 | BOLT | 375872 | 247229 |
92 | EXPANDER SPRING | 404759 | 245501 |
93 | PISTON RING | 412289 | 245502 |
94 | 3RD CLUTCH | ||
95 | LOCKWASHER | 307028 | 4E-08 |
96 | CAPSCREW | 305029 | 1C-820 |
97 | SNAP RING | 400793 | 247470 |
98 | SNAP RING | 400793 | 247470 |
99 | 4TH CLUTCH | ||
100 | EXPANDER SPRING | 404759 | 245501 |
101 | PISTON RING | 412289 | 245502 |
102 | BOLT | 375872 | 247229 |
103 | SUPPORT ASSEMBLY | 353927 | 237169 |
104 | NUT | 378923 | 245519 |
105 | BEARING | 334003 | 225844 |
106 | WASHER | 333739 | 222181 |
107 | SPACER | 333405 | 217502 |
108 | GEAR | 341456 | 217359 |
109 | GEAR | 351152 | 235324 |
110 | ELBOW | 339992 | 26F-3 |
111 | BREATHER | 359700 | 238535 |
112 | SNAP RING | 333835 | 223982 |
113 | BEARING ASSEMBLY | 333957 | 225400 |
114 | SHAFT | 411254 | 245690 |
115 | SUPPORT ASSEMBLY | 333351 | 217128 |
116 | BOLT | 375872 | 247229 |
117 | RING | 346189 | 233947 |
118 | PISTON RING | 346190 | 233948 |
119 | COTTER PIN | 329984 | 1F-632 |
120 | 2ND CLUTCH | ||
121 | SNAP RING | 378941 | 247717 |
122 | SCREW | 340003 | 25G-612 |
123 | WASHER | 339963 | 6E-06 |
124 | WASHER | 353781 | 237328 |
125 | CAPSCREW | 333103 | 21C-612 |
126 | NUT | 354022 | 201262 |
127 | WASHER | 333739 | 222181 |
128 | O RING | 400695 | 25K-60204 |
129 | FLANGE | 333395 | 217457 |
130 | CAPSCREW | 305029 | 1C-820 |
131 | LOCKWASHER | 307028 | 4E-08 |
132 | BEARING CAP | 353782 | 217625 |
133 | O RING | 340143 | 25K-40408 |
134 | OIL SEAL | 333983 | 225763 |
135 | BEARING CUP | 404764 | 247581 |
136 | BEARING CONE | 340824 | 225850 |
137 | OUTPUT SHAFT | 333536 | 218703 |
138 | GEAR | 333377 | 217343 |
139 | PLUG | 307892 | 11F-12 |
140 | WASHER | 353781 | 237328 |
141 | CAPSCREW | 333103 | 21C-612 |
142 | SUMP ASSEMBLY | 333427 | 217562 |
143 | MAGNET | 400675 | 525293 |
144 | GASKET | 353213 | 237154 |
145 | CAPSCREW | 305056 | 1C-636 |
146 | LOCKWASHER | 307029 | 4E-06 |
147 | GASKET | 333533 | 218376 |
148 | FRAME & SCREEN ASSEMBLY | 371564 | 242881 |
149 | GEAR | 405034 | 217358 |
150 | BEARING CONE | 340824 | 225850 |
151 | BEARING CUP | 404764 | 247581 |
152 | OIL SEAL | 333983 | 225763 |
153 | O RING | 340143 | 25K-40408 |
154 | SHIM | 333485 | 217686 |
155 | SHIM | 333486 | 217687 |
156 | SHIM | 333487 | 217688 |
157 | BEARING CAP | 353782 | 217625 |
158 | FLANGE | 333395 | 217457 |
159 | LOCKWASHER | 307028 | 4E-08 |
160 | CAPSCREW | 305029 | 1C-820 |
161 | O RING | 400695 | 25K-60204 |
162 | WASHER | 333739 | 222181 |
163 | COTTER PIN | 329984 | 1F-632 |
164 | NUT | 354022 | 201262 |
165 | GASKET | 353214 | 237158 |
166 | COVER | 333457 | 217619 |
167 | WASHER | 353781 | 237328 |
168 | CAPSCREW | 333103 | 21C-612 |
169 | PLUG | 336269 | 40K-04 |
170 | CASE ASSEMBLY | 363183 | 237858 |
171 | TUBE | 333504 | 217708 |
172 | TUBE | 333506 | 217710 |
173 | TUBE | 333505 | 217709 |
174 | SLEEVE | 333733 | 222067 |
175 | SLEEVE | 333733 | 222067 |
176 | TUBE | 344092 | 217698 |
177 | TUBE CLIP | 337368 | 6H-29 |
178 | RIVET | 329996 | 1H-516 |
179 | FLATWASHER | 599231 | 25E-15 |
180 | RIVET | 329997 | 1H-534 |
181 | FLATWASHER | 599231 | 25E-15 |
182 | RIVET | 337368 | 6H-29 |
183 | FLATWASHER | 599230 | 25E-13 |
184 | RIVET | 329994 | 1H-416 |
185 | TUBECLIP | 337369 | 6H-32 |
186 | TUBE | 371567 | 242924 |
187 | TUBE | 333502 | 217706 |
188 | TUBE | 333494 | 217699 |
189 | TUBE | 363184 | 238748 |
190 | TUBE | 363185 | 239182 |
191 | TUBE | 363186 | 238747 |
192 | TUBE | 333496 | 217700 |
193 | TUBE | 333501 | 217705 |
194 | TUBE | 371568 | 242772 |
195 | SLEEVE | 355985 | 221871 |
196 | SLEEVE | 355985 | 221871 |
197 | HUB ASSEMBLY | 400035 | 245503 |
198 | SPRING | 377590 | 245505 |
199 | SPRING PIN | 333450 | 217599 |
200 | DISC | 365332 | 238174 |
201 | DISC | 334055 | 227495 |
202 | PLATE | 333368 | 217161 |
203 | SNAP RING | 333350 | 217099 |
204 | PISTON | 333370 | 217164 |
205 | RING | 341457 | 217361 |
206 | PISTON RING | 333385 | 217411 |
207 | SNAP RING | 376985 | 245980 |
208 | SNAP RING | 376986 | 245981 |
209 | WASHER | 376987 | 245982 |
210 | WASHER | 376988 | 245983 |
211 | WASHER | 376989 | 245984 |
212 | BEARING CONE | 353932 | 237183 |
213 | BEARING CUP | 353931 | 237184 |
214 | RACE | 333364 | 217155 |
215 | BALL | 330092 | 10J-08 |
216 | BALL CLUTCH DRUM ASSEMBLY | 355114 | 237179 |
217 | BEARING CUP | 353928 | 237182 |
218 | BEARING CONE | 353929 | 237181 |
219 | BAFFLE RING | 333411 | 217510 |
220 | HUB ASSEMBLY | 401292 | 248290 |
221 | SPRING | 377590 | 245505 |
222 | SPRING PIN | 333450 | 217599 |
223 | DISC | 339692 | 232285 |
224 | DISC | 339705 | 232779 |
225 | PLATE | 333355 | 217137 |
226 | SNAP RING | 333387 | 217416 |
227 | PISTON | 333356 | 217138 |
228 | EXPANDER SPRING | 405036 | 245140 |
229 | PISTON RING | 405037 | 245139 |
230 | PISTON | 376395 | 246248 |
231 | EXPANDER SPRING | 376393 | 239694 |
232 | SNAP RING | 338045 | 791018 |
233 | WASHER | 354511 | 237520 |
234 | SNAP RING | 333835 | 223982 |
235 | BEARING | 333985 | 225768 |
236 | RACE | 333354 | 217136 |
237 | BALL | 330092 | 10J-08 |
238 | CLUTCH DRUM ASSEMBLY | 333352 | 217130 |
239 | BEARING | 355115 | 236781 |
240 | SNAP RING | 333820 | 223852 |
241 | GEAR | 350429 | 233714 |
242 | SNAP RING | 333491 | 217692 |
243 | CONTROL VALVE ASSEMBLY | 373610 | 242510 |
244 | PLUG | 334052 | 227418 |
245 | O RING | 367144 | 91F-7 |
246 | 3RD SPEED VALVE | 334091 | 228096 |
247 | HOSUING | 342539 | 228094 |
248 | 3RD SPEED VALVE STOP PIN | 330450 | 106358 |
249 | WASHER | 407844 | 743314 |
250 | PLUG | 334054 | 227423 |
251 | 2ND SPEED VALVE STOP PIN | 330450 | 106358 |
252 | O RING | 334947 | 25K-30030 |
253 | 2ND SPEED VALVE STOP PIN | 334090 | 228095 |
254 | 1ST SPEED VALVE | 342531 | 227550 |
255 | PLUG | 334591 | 24K-10 |
256 | PIN | 339731 | 300058 |
257 | LOCK PIN | 337658 | 654724 |
258 | PLUG | 336268 | 40K-02 |
259 | PLUG | 334053 | 227422 |
260 | WASHER | 407614 | 731964 |
261 | SELECTOR VALVE ASSEMBLY | 420932 | 227555 |
262 | VALVE PLUG | 420933 | 227556 |
263 | O RING | 334947 | 25K-30030 |
264 | VALVE SPRING | 334062 | 227558 |
265 | HOUSING PLUG | 334061 | 227557 |
266 | ADAPTOR UNION | 339994 | 36F-1 |
267 | SNAP RING | 401137 | 664140 |
268 | PISTON GUIDE | 373436 | 241396 |
269 | O RING | 372760 | 25K-20030 |
270 | PISTON GUIDE | 373437 | 241409 |
271 | CAP STOP | 373438 | 241399 |
272 | SPACER | 373439 | 241402 |
273 | SPRING | 373440 | 241398 |
274 | SLEEVE | 373441 | 244467 |
275 | PLUG | 334053 | 227422 |
276 | WASHER | 407614 | 731964 |
277 | PLUG | 307400 | 16F-08 |
278 | SPOOL | 409113 | 241404 |
279 | PISTON GUIDE | 373437 | 241409 |
280 | O RING | 372760 | 25K-20030 |
281 | PISTON GUIDE | 373436 | 241396 |
282 | SNAP RING | 401137 | 247475 |
283 | ADAPTOR UNION | 339994 | 36F-1 |
284 | PLUG | 007212 | 24K-7 |
285 | O RING | 367144 | 91F-7 |
286 | VALVE SPOOL | 333471 | 217644 |
287 | VALVE SPRING | 333472 | 217645 |
288 | VALVE STOP | 333689 | 220983 |
289 | O RING | 340124 | 25K-30018 |
290 | O RING | 334948 | 25K-40024 |
291 | SPOOL STOP | 333732 | 222041 |
292 | VALVE SPOOL | 369206 | 239527 |
293 | LOCKWASHER | 307029 | 5E-05 |
294 | CAPSCREW | 305010 | 1C-512 |
295 | COVER | 373443 | 241401 |
296 | PLUG | 336269 | 40K-04 |
297 | INNER SPRING | 333475 | 217648 |
298 | OUTER SPRING | 333476 | 217649 |
299 | SPOOL STOP | 333732 | 222041 |
300 | O RING | 334948 | 25K-40024 |
301 | O RING | 334948 | 25K-40024 |
302 | SPRING STOP | 333732 | 222041 |
303 | SAFETY VALVE SPRING | 366916 | 240140 |
304 | SAFETY VALVE SPACER | 3334790 | 217652 |
305 | SAFETY VALVE BALL | 330097 | 10J-24 |
306 | SAFETY VALVE SEAT | 333477 | 217650 |
307 | COVER PLATE | 333466 | 217632 |
308 | PLUG | 355112 | 1300085 |
309 | PLUG | 36486 | 239245 |
Item | Name | Epiroc Part No. |
1 | ROCK TORQUE AXLE ASSY | 5571554200 |
2 | AXLE HOUSING | 5540626500 |
3 | PLUG ASSEMBLY | 5540510500 |
4 | MAGNETICPLUG | 5540752200 |
5 | BREATHER | 5540589400 |
6 | DOWEL PIN | 5537878000 |
7 | DOWEL PIN | 5540062800 |
8 | AXLE SHAFT | 5540752400 |
9 | SPINDLE | 5540267400 |
10 | O-RING | 5540057700 |
11 | SPRING COVER | 5540058500 |
12 | SPRING PIN | 5540475600 |
13 | O-RING | 5537884700 |
14 | BREATHER | 5537885300 |
15 | CAP | 5537885400 |
16 | SPRING | 5537885200 |
17 | SPRING | 5540058700 |
18 | BOLT | 5540058900 |
19 | WASHER | 5540059500 |
20 | BOLT | 5540001800 |
21 | O-RING | 5540058600 |
22 | SEAL CAP | 5541537800 |
23 | PISTON | 5540059100 |
24 | SEAL CAP | 5541537700 |
25 | BRAKE HOUSING | 5540928300 |
26 | PLUG | 5540589700 |
27 | O-RING | 5540058100 |
28 | STATOR | 5540991300 |
29 | FRICTION PLATE | 5540059200 |
30 | COVER | 5540589800 |
31 | BOLT | 5540058800 |
32 | FLOATING SEAL KIT | 5541341400 |
33 | HUB SEAL | 5540871000 |
34 | BEARING | 5540268100 |
35 | WHEEL HUB | 5540752900 |
36 | STUD | 5540136800 |
37 | BEARING | 5540268200 |
38 | RETAINING RING | 5540002500 |
39 | RING GEAR HOLDER | 5540590100 |
40 | LOCK PLATE | 5540590200 |
41 | BOLT | 5540590300 |
42 | COLLAR | 5540590400 |
43 | NUT | 5540590500 |
44 | WASHER | 5540959800 |
45 | DRIVE GEAR | 5540268000 |
46 | RETAINING RING | 5540382100 |
47 | THRUST WASHER | 5540836700 |
48 | RING GEAR | 5540267900 |
49 | O-RING KIT | 5540753100 |
50 | CARRIER KIT | 5540938900 |
51 | PLANET CARRIER | 5540590800 |
52 | PLANET GEAR | 5540267600 |
53 | NEEDLE BEARING | 5540267700 |
54 | WASHER | 5540101000 |
55 | PLANET SHAFT | 5540590900 |
56 | O-RING KIT | 5540753100 |
57 | SETSSCREW | 5540101300 |
58 | BOLT | 5540101400 |
59 | COVER | 5540591100 |
60 | BOLT | 5540101600 |
61 | BOLT | 5540382400 |
62 | BOLT | 5540382500 |
63 | SPRING WASHER | 5537874100 |
64 | DIFFERENTIAL CARRIER ASSEMBLY | 5571443700 |
65 | BOLT | 5540382600 |
66 | DIFFERENTIAL CASE SET | 5540382700 |
67 | BEVEL GEAR SET | 5540266200 |
68 | WASHER | 5540266900 |
69 | SIDE GEAR | 5540266800 |
70 | WASHER | 5541566200 |
71 | PINION GEAR | 5540267000 |
72 | SPIDER | 5541566300 |
73 | DOWEL PIN | 5537877900 |
74 | BOLT | 5540382800 |
75 | BOLT | 5540384500 |
76 | LOCKWASHER | 5537878200 |
77 | LOCK PLATE | 5537878100 |
78 | BEARING | 5540266100 |
79 | ADJUSTING NUT | 5540413000 |
80 | BEARING CAP SET | 5540591200 |
81 | LOCK PLATE | 5540383100 |
82 | BOLT | 5537878600 |
83 | LOCK RING | 5540383200 |
84 | BEARING | 5540383300 |
85 | SHIM KIT | 5540266300 |
86 | BEARING | 5540057300 |
87 | RETAINER | 5540383400 |
88 | COLLAR KIT | 5540383500 |
89 | BEARING | 5540266600 |
90 | BEARING | 5540268800 |
91 | OIL SEPARATOR | 5537879100 |
92 | OIL SEAL | 5540383600 |
93 | BOLT | 5537873500 |
94 | DUST COVER | 5540266400 |
95 | FLANGE | 5537877600 |
96 | WASHER | 5537879500 |
97 | CASTLE NUT | 5537879400 |
98 | COTTER PIN | 5537813700 |
99 | AXLE SHAFT | 5540752300 |
100 | BOLT | 5540384300 |
101 | NUT | 5540384400 |
102 | BOLT | 5540591300 |
103 | NUT | 5540591400 |
Item | Name | Epiroc Part No. |
1 | ROCK TORQUE AXLE ASSY | 5571554200 |
2 | AXLE HOUSING | 5540626500 |
3 | PLUG ASSEMBLY | 5540510500 |
4 | MAGNETICPLUG | 5540752200 |
5 | BREATHER | 5540589400 |
6 | DOWEL PIN | 5537878000 |
7 | DOWEL PIN | 5540062800 |
8 | AXLE SHAFT | 5540752400 |
9 | SPINDLE | 5540267400 |
10 | O-RING | 5540057700 |
11 | SPRING COVER | 5540058500 |
12 | SPRING PIN | 5540475600 |
13 | O-RING | 5537884700 |
14 | BREATHER | 5537885300 |
15 | CAP | 5537885400 |
16 | SPRING | 5537885200 |
17 | SPRING | 5540058700 |
18 | BOLT | 5540058900 |
19 | WASHER | 5540059500 |
20 | BOLT | 5540001800 |
21 | O-RING | 5540058600 |
22 | SEAL CAP | 5541537800 |
23 | PISTON | 5540059100 |
24 | SEAL CAP | 5541537700 |
25 | BRAKE HOUSING | 5540928300 |
26 | PLUG | 5540589700 |
27 | O-RING | 5540058100 |
28 | STATOR | 5540991300 |
29 | FRICTION PLATE | 5540059200 |
30 | COVER | 5540589800 |
31 | BOLT | 5540058800 |
32 | FLOATING SEAL KIT | 5541341400 |
33 | HUB SEAL | 5540871000 |
34 | BEARING | 5540268100 |
35 | WHEEL HUB | 5540752900 |
36 | STUD | 5540136800 |
37 | BEARING | 5540268200 |
38 | RETAINING RING | 5540002500 |
39 | RING GEAR HOLDER | 5540590100 |
40 | LOCK PLATE | 5540590200 |
41 | BOLT | 5540590300 |
42 | COLLAR | 5540590400 |
43 | NUT | 5540590500 |
44 | WASHER | 5540959800 |
45 | DRIVE GEAR | 5540268000 |
46 | RETAINING RING | 5540382100 |
47 | THRUST WASHER | 5540836700 |
48 | RING GEAR | 5540267900 |
49 | O-RING KIT | 5540753100 |
50 | CARRIER KIT | 5540938900 |
51 | PLANET CARRIER | 5540590800 |
52 | PLANET GEAR | 5540267600 |
53 | NEEDLE BEARING | 5540267700 |
54 | WASHER | 5540101000 |
55 | PLANET SHAFT | 5540590900 |
56 | O-RING KIT | 5540753100 |
57 | SETSSCREW | 5540101300 |
58 | BOLT | 5540101400 |
59 | COVER | 5540591100 |
60 | BOLT | 5540101600 |
61 | BOLT | 5540382400 |
62 | BOLT | 5540382500 |
63 | SPRING WASHER | 5537874100 |
64 | DIFFERENTIAL CARRIER ASSEMBLY | 5571443700 |
65 | BOLT | 5540382600 |
66 | DIFFERENTIAL CASE SET | 5540382700 |
67 | BEVEL GEAR SET | 5540266200 |
68 | WASHER | 5540266900 |
69 | SIDE GEAR | 5540266800 |
70 | WASHER | 5541566200 |
71 | PINION GEAR | 5540267000 |
72 | SPIDER | 5541566300 |
73 | DOWEL PIN | 5537877900 |
74 | BOLT | 5540382800 |
75 | BOLT | 5540384500 |
76 | LOCKWASHER | 5537878200 |
77 | LOCK PLATE | 5537878100 |
78 | BEARING | 5540266100 |
79 | ADJUSTING NUT | 5540413000 |
80 | BEARING CAP SET | 5540591200 |
81 | LOCK PLATE | 5540383100 |
82 | BOLT | 5537878600 |
83 | LOCK RING | 5540383200 |
84 | BEARING | 5540383300 |
85 | SHIM KIT | 5540266300 |
86 | BEARING | 5540057300 |
87 | RETAINER | 5540383400 |
88 | COLLAR KIT | 5540383500 |
89 | BEARING | 5540266600 |
90 | BEARING | 5540268800 |
91 | OIL SEPARATOR | 5537879100 |
92 | OIL SEAL | 5540383600 |
93 | BOLT | 5537873500 |
94 | DUST COVER | 5540266400 |
95 | FLANGE | 5537877600 |
96 | WASHER | 5537879500 |
97 | CASTLE NUT | 5537879400 |
98 | COTTER PIN | 5537813700 |
99 | AXLE SHAFT | 5540752300 |
100 | BOLT | 5540384300 |
101 | NUT | 5540384400 |
102 | BOLT | 5540591300 |
103 | NUT | 5540591400 |
